Room thermostat TGT70-AC2 for 2 pipe fancoil

Wishlist
Compare
Send
- VK
- WhatsApp
- Odnoklassniki
- Copy link

Model:
010.003.162

Electronic thermostat TGT70-AC2 is designed to automatically maintain the temperature in the room at a user-defined value by regulating the speed of rotation of fans of heating devices (convectors), as well as control valves with electric actuators.

$58.91

Available: 59 pcs

pcs

Thermostat characteristics

Product name	TGT70-AC2
Specific application	2-pipe fancoil unit
Supply voltage	200-240VAC
WiFI control	no
Colour	black
Max valve relay resistance	3A~5A
Housing material	fireproof plastic (PC+ABS)
Sensor	NTC
Temperature control limits	+10…+40°C
Measurement accuracy	±1 °C
Storage temperature	-5…+55°C
Power consumption	≤0.5W
Operating temperature	0…+45°C (at 5-95% humidity)
Accuracy of built-in clock	<1 %
Dimensions	86 х 86 х 13.3 mm
Weight	0.262 kg
