Capillary thermostat WKB-60S2 16A/250VAC

  • Model:
    010.002.137
  • Copy
  • photo 3
  • photo 4
  • photo 5
  • photo 6
  • photo 7
  • photo 8
Thermostat WKB-60S2
Adjustable single-pole capillary thermostat WKB-60S2 with handle is intended to maintain the required temperature in a device or its parts. A rise in temperature causes the expansion of liquid within the bulb and capillary. The liguid acts on a diaphragm within the plastic housing to open electrical contacts.
Area of application - conditioners, heaters, air curtains.
Rated current: 16A/250VAC.
$3.85
 pcs

Specification

Temperature adjusting range0…+60°C
Differential4±2°C
Material of the capillary and bulbstainless steel
Electric rating16A/250VAC
Dielectric strength2000VAC / 1 min / 0.5 mA
Max bulb temperature80°C
Max housing temperature125°C
Life> 100 000 cycles

Thermostat dimensions

Capillary thermostat WKB-60S2 dimensions

Handle dimensions

Handle with scale 0…60°C
