Capillary thermostat WKB-120S1 16A/250VAC

  • Model:
    010.002.095
  • Copy
  • photo 3
  • photo 4
  • photo 5
Thermostat WKB-120S1
Adjustable single-pole capillary thermostat WKB-120S1 is intended for support of given temperature in the controllable device or its parts. A rise in temperature causes the expansion of liquid within the bulb and capillary. The liquid acts on a bellows assembly within the plastic housing to open electrical contacts.
Temperature adjusting range 0…120°C.
Electric rating: 16A/250VAC.
Stainless steel bulb and capillary.

Specifications

Bulb and capillary materialstainless steel
Temperature adjusting range0°C…120°C
Temperature in positionH: 120±4°C
Differential5±3°C
Electric rating16A/250VAC
Testing conditionstemperature changing rate ≤1°C/min
Max temperature of the bulb180°C
Max temperature of the case125°C
Life50 000 cycles

Dimensions

Capillary thermostat WKB-120S1 dimensions
