Cross-flow fan JQF20.60.180R 35W/220VAC

  • Model:
    011.012.106
  • Copy
  • photo 3
  • photo 4
  • photo 5
  • photo 6
  • photo 7
  • photo 8
  • photo 9
Cross-flow blower JQF20.60.180R
Cross-flow fan JQF20.60.180R creates wide uniformly directed air flow by means of tangential fan wheel. It is intended to be used as a ventilation unit in air curtains, conditioners, etc for aeration and cooling down the required objects.
  • Supply voltage 220VAC 50Hz
  • Input power 35W
  • Speed 2000rpm
  • Insulation class H
$17.58
Available: 2032 pcs
 pcs

Technical data

Supply voltage220VAC 50Hz
Input power35W
Current≤ 0.32А
Insulation classH
Speed2000rpm
Temperature rise≤ 75K
Max air flow180 m3/h
Bearing typesleeve bearing
Start voltage170V
Hi-pot1800V/1s

Dimensions

Cross-flow fan JQF20.60.180R dimensions

Auxiliaries and accessories for JQF20.60.180R
