Circuit breaker S202 C25 2CDS252001R0254 2P 25A C 6kA

  • Model: 003.041.047
Circuit breaker S202 C25 2CDS252001R0254
Manufacturer: ABB
Barcode: 4016779466103
Circuit breaker S202 C25 2CDS252001R0254 S200 series is designed to protect chains from overload and short circuits, protect resistive and inductive loads with low pulse current. It is used in residential premises, commercial and industrial facilities.
$13.80
 pcs

Specification

General data
Number of poles2
Tripping characteristicC
Rated current In25A
Rated insulation voltage Ui250VAC (phase to ground)
500VAC (phase to phase)
Overvoltage categoryIII
Pollution degree3
Rated operational voltage Un400VAC (IEC/EN 60898-1)
400VAC (IEC/EN 60947-2)
Rated short-circuit capacity Icn IEC/EN 60898-16kA
Rated ultimate short-circuit breaking capacity Icu IEC/EN 60947-210kA
Rated service short-circuit breaking capacity Ics IEC/EN 60947-27,5kA
Rated impulse withstand voltage Uimp4kV
Energy limiting class IEC/EN 60898-13
Reference temperature for tripping characteristics30°C (IEC/EN 60898-1)
55°C (IEC/EN 60947-2)
Electrical endurance20 000 ops
Mechanical data
Protection degreeIP20 (open)
IP40 (in enclosure with cover)
Mechanical endurance20 000 ops
Ambient temperature-25°C...+55°C
Storage temperature-40°C...+70°C
Installation
Cross-section of conductors (top/bottom)25mm2
Cross-section of busbars (top/bottom)10mm2
Tightening torque2,8 N·m
Mounting35mm DIN rail
Mounting positionany

Dimensions

Circuit breaker S200 dimensions 2P

Tripping curve

Tripping curve C

Range of ABB S200 series circuit breakers

Number of poles 1 1+N 2 3 3+N 4
Single-pole circuit breaker Single-pole circuit breaker with neutral disconnection Two-pole circuit breaker Three-pole circuit breaker Three-pole circuit breaker with neutral disconnection Four-pole circuit breaker
Rated current, A Tripping curve C
0,5 2CDS251001R0984 2CDS251103R0984 2CDS252001R0984 2CDS253001R0984 2CDS253103R0984 2CDS254001R0984
1 2CDS251001R0014 2CDS251103R0014 2CDS252001R0014 2CDS253001R0014 2CDS253103R0014 2CDS254001R0014
1.6 2CDS251001R0974 2CDS251103R0974 2CDS252001R0974 2CDS253001R0974 2CDS253103R0974 2CDS254001R0974
2 2CDS251001R0024 2CDS251103R0024 2CDS252001R0024 2CDS253001R0024 2CDS253103R0024 2CDS254001R0024
3 2CDS251001R0034 2CDS251103R0034 2CDS252001R0034 2CDS253001R0034 2CDS253103R0034 2CDS254001R0034
4 2CDS251001R0044 2CDS251103R0044 2CDS252001R0044 2CDS253001R0044 2CDS253103R0044 2CDS254001R0044
6 2CDS251001R0064 2CDS251103R0064 2CDS252001R0064 2CDS253001R0064 2CDS253103R0064 2CDS254001R0064
8 2CDS251001R0084 2CDS251103R0084 2CDS252001R0084 2CDS253001R0084 2CDS253103R0084 2CDS254001R0084
10 2CDS251001R0104 2CDS251103R0104 2CDS252001R0104 2CDS253001R0104 2CDS253103R0104 2CDS254001R0104
13 2CDS251001R0134 2CDS251103R0134 2CDS252001R0134 2CDS253001R0134 2CDS253103R0134 2CDS254001R0134
16 2CDS251001R0164 2CDS251103R0164 2CDS252001R0164 2CDS253001R0164 2CDS253103R0164 2CDS254001R0164
20 2CDS251001R0204 2CDS251103R0204 2CDS252001R0204 2CDS253001R0204 2CDS253103R0204 2CDS254001R0204
25 2CDS251001R0254 2CDS251103R0254 2CDS252001R0254 2CDS253001R0254 2CDS253103R0254 2CDS254001R0254
32 2CDS251001R0324 2CDS251103R0324 2CDS252001R0324 2CDS253001R0324 2CDS253103R0324 2CDS254001R0324
40 2CDS251001R0404 2CDS251103R0404 2CDS252001R0404 2CDS253001R0404 2CDS253103R0404 2CDS254001R0404
50 2CDS251001R0504 2CDS251103R0504 2CDS252001R0504 2CDS253001R0504 2CDS253103R0504 2CDS254001R0504
63 2CDS251001R0634 2CDS251103R0634 2CDS252001R0634 2CDS253001R0634 2CDS253103R0634 2CDS254001R0634
